제품 상세 정보:
결제 및 배송 조건:
|
| 베어링 유형: | 계측기 보호를 견디는 봉인한 언론지 | 자르는 소재: | 텅스텐 카바이드 |
|---|---|---|---|
| 표준: | API-7-1, ISO 9001:2008 | 시리즈: | FHO |
| IADC: | 537 | 신청 1: | 파인곳 없습니다 |
| 애플리케이션 2: | 개공구 드릴링 | ||
| 하이 라이트: | 가득 찬 HDD 개공구 IADC 537,중경질 HDD 록 리머,파인곳 없는 HDD 개공구 |
||
HDD Hole Openers , Reamer , IADC 537 , Single Cone Bit , Trenchless , Medium Hard Rock Reamer
1. Hole openers are designed for the enlargement of pilot holes and large hole applications. They are also used for road and river crossing application.
2. The hole openers are manufactured from AISI 4145H fully heat-treated alloy steel. All are available with carbide-milled teeth and insert cutters. Arms and cutters are hardfaced for protection in three different designs for varying conditions and rock formations. The design of the hole opener allows for field-changing the cutters. They has a wide range of hole opener types, including.
Cutting Structure
Combined by single TCI cone bit, IADC 537.
Seal and Lubrication
High performance HNBR O-ring for bearing seal and advanced grease for lubrication.
Product Application
It is suitable for the large size well, HDD, trenchless and infrastructure applications.
Specifications:
It is suitable for the large size well, mining and infrastructure applications.
| Size | Bit Type |
|
| In. | mm | |
| 28 | 711.2 | 117, 127, 517, 537, 617, 637 |
| 32 | 812.8 | 117, 127, 517, 537, 617, 637 |
| 38 | 914.4 | 117, 127, 517, 537, 617, 637 |
